Vacuum Hot Water Boiler is safe and energy saving heating equipment. Work under negative pressure condition (vacuum), lowers the boiling point of water, greatly reduce the gas temperature, the boiler work under low temperature and low pressure conditions with high thermal efficiency.
Vacuum structure make oxygen corrosion, scaling small and service life longer. Suitable for hot water supply, heating and industrial hot water heating equipment.
Feature
1、Vacuum operating, Low pressure and low temperature
2、Energy saving, less heat loss
3、Anti scaling and anti-corrosion prolong service life
4、Compact structure, easy installation and use
5、Suitable for automatic control system
| Rated Power (MW) | 0.7 | 1.05 | 1.4 | 2.1 | 2.8 | 3.5 | 4.2 | 5.6 | 7 |
| Boiler Rated Operating Pressure | -0.02MPa | ||||||||
| Inlet/Return Water Temperature (°C) | 80/60 | ||||||||
| Radiant Heating Surface (m²) | 5.54 | 6.27 | 7.2 | 11.8 | 14.9 | 17 | 19.2 | 21.1 | 22.8 |
| Convection Heating Surface (m²) | 16.1 | 21.8 | 33.28 | 57.24 | 79.68 | 92.7 | 116.92 | 127.98 | 187.44 |
| Ecosystem Heater Heating Surface (m²) | / | / | 19.4 | 25.8 | 29.1 | 32.6 | 42.87 | 58.89 | 85.66 |
| Heat Exchanger Rated Operating Pressure | 1.0MPa | ||||||||
| Heat Exchanger Heating Surface (m²) | 13.92 | 21.56.8 | 32.54 | 48.76 | 82..56 | 105.66 | 115.3 | 131.79 | 171.14 |
| Circulating Water Flow Rate (m³) | 30 | 45 | 60 | 90 | 120 | 150 | 180 | 240 | 300 |
| Thermal Efficiency (Oil/Natural Gas) | 92.33% | 94.54% | 94.29% | 95.8% | 95.35% | 95.37% | 95.32% | 95.02% | 95.66% |
| 92.02% | 94.26% | 94.45% | 95.58% | 95.30% | 95.11% | 95.21% | 94.94% | 95.42% | |
| Fuel Consumption (Oil kg/h) | 61.93 | 96.28 | 120.67 | 178.91 | 238.27 | 297.8 | 359.7 | 478.3 | 593.7 |
| Fuel Consumption (Natural Gas kg/h) | 74.9 | 116.47 | 146.4 | 217.31 | 288.72 | 361.6 | 436.73 | 579.7 | 720.9 |
| Water Capacity (T) | 1.68 | 3.16 | 3.4 | 5.11 | 6.2 | 8.5 | 9.3 | 10.6 | 15 |
| Transport Dimensions (mm) | 3596x1492x2286 | 3627x1672x2383 | 4189x1846x2716 | 4980x2020x2920 | 5285x2280x3260 | 5605x2494x3696 | 5705x2500x3696 | 6125x3813x3260 | 7180x2800x3940 |
